Spectrum PET-G Carbon
Carbon Fiber Reinforced | Extreme Rigidity | Matte Industrial Finish | 0.50kg-2kg
Spectrum PET-G Carbon is a high-performance, carbon fiber-reinforced composite material based on premium PET-G. By integrating specialized carbon fibers into the polymer matrix, we have significantly increased the material's stiffness and tensile strength while maintaining the excellent chemical resistance and ease of use that PET-G is known for.
This filament delivers a stunning deep matte black surface that naturally hides layer lines, providing a professional "machined" look. The addition of carbon fiber also improves the thermal resistance and dimensional stability of the printed parts, making it an ideal choice for components that must resist deformation under load.
Unlike standard PET-G, the Carbon version offers a much higher Elastic Modulus. This means your parts will be far more rigid and less prone to bending, making it the perfect solution for drone frames, mounting brackets, and functional mechanical linkages.
🚀 Extreme Stiffness
The carbon fiber reinforcement significantly reduces part flex, ensuring high rigidity for structural frames.
📐 Improved Dimensional Stability
Carbon fibers minimize thermal shrinkage during cooling, leading to superior accuracy for tight-tolerance assemblies.
🏁 Premium Matte Finish
Achieve a high-end industrial aesthetic with a non-reflective surface that beautifully masks layer transitions.
🔨 High Interlayer Bonding
Carefully optimized to maintain the legendary layer adhesion of PET-G, preventing delamination under stress.
- Lightweight structural drone (UAV) components
- Custom automotive interior trims and brackets
- Functional mechanical jigs and factory tooling
- End-use housings for handheld electronics
- High-load sports equipment and frames
- Prototyping parts for aerospace and defense
| Material Identity & Structural Profile | |
|---|---|
| Producer / Series | Spectrum Filaments / Industrial Carbon |
| Material Type | PET-G + 10% Carbon Fiber |
| Filament Diameter | 1.75 mm ± 0.05 mm |
| Color Name | Carbon Black (Ultra Matte) |
| Heat Deflection Temp (HDT) | ~ 75°C - 80°C |
| Net Weight | 0.50 kg (Compact Spool)-2 kg |
| EAN / SKU | 5903116680651 / 80077 |
| Nozzle Temperature | 235 - 255°C |
| Heated Bed Temperature | 60 - 80°C |
| Nozzle Type | Hardened Steel (Recommended) |
| Print Speed | 30 - 60 mm/s |
| Cooling Fan Speed | 0 - 30% (Low for best layer strength) |
| Bed Adhesive | Magigoo / PEI / 3DLAC |
| Diameter Accuracy | Carbon Loading | Protection | Compliance |
|---|---|---|---|
| ±0.05 mm (2-Axis Laser) | 10% Uniform Fiber Dispersion | Vacuum Sealed + Desiccant | Individual QR Code Quality Report |
Essential documentation for structural engineering and material validation:
* Engineer's Tip: Carbon fiber is abrasive. To maintain the accuracy of your prints over time, we strongly recommend using a hardened steel nozzle. Brass nozzles will wear down quickly when extruding carbon-filled materials.
